Galfan Gabion Mattress For River Band And Slope Protection PVC Coated Gabion Box
PVC Coated Gabion Box introduction:
Stone filled baskets are called Gabions, Gabion baskets etc. The
usage of Welded gabion baskets are being accepted world wide for
soil prevention at river banks, ponds, lakes, sea coasts, bridges
etc. Also it is being utilised for landscaping in residential town
ships, universities, schools, public gardens, schools etc in
today's life.
PVC Coated Gabion Box Material:
Mesh wire/body wire: 2-4mm.
selvage wire: 0.5-1mm thicker than mesh wire.
lacing wire/tie wire: thinner than mesh wire, usually 2.2mm.
PVC Coated Gabion Box Specification:
| Material | Galvanized wire |
| Hot dipped galvanized (Zinc Coated) |
| Galfan coated: 95% Zinc + 5% Aluminum, 90%Zinc +10% Aluminum | |
| Zinc(galvanized) + PVC Coated (Gray or Green) |
| Gabion Basket/Gabion Box/Gabion Mesh/Gabion Cage Specification | ||||
| Wire diameter | 2.0-4.0mm | |||
| Mesh opening | 80 x 100mm | 90 x 110mm | 100 x 120mm | 60 x 80mm etc. |
| Dimension | 1x0.5x0.5m, 1x1x1m, 2x1x0.5m, 2x1x1m, 3x1x0.5m, 3x2x0.3m,
3x2x0.17m, 3x1x1m, 4x1x0.5m, 4x1x1m, 4x2x0.3m, 5x1x1m, 5x1x0.5m, 6x2x0.3m or as request | |||
| Material | galvanzied wire |
| Wire diameter | 2.0-4.0mm |
| Mesh Size | 60*80mm, 80*100mm, 80*120mm, 100*120mm, 100*150mm, 120*150mm |
| Surface treatment | hot-dipped galvanzied/PVC coated |
| Color | silver/green/black green |
| Application | soil, bridge construction, water bank |
| Specifications offered | |||||
| Length | Width | Height | Diaphragm | CUM | The tolerance |
| M | M | M | Unit | M3 | |
| 2 | 1 | 0.3 | 1 | 0.6 | |
| 3 | 1 | 0.3 | 2 | 0.9 | |
| 4 | 1 | 0.3 | 3 | 1.2 | length+-3% |
| 2 | 1 | 0.5 | 1 | 1 | width+-5% |
| 3 | 1 | 0.5 | 2 | 1.5 | height+-5% |
| 4 | 1 | 0.5 | 3 | 2 | |
| 1 | 1 | 0.5 | 0 | 1 | Hole size |
| 1.5 | 1 | 1 | 0 | 1.5 | 60x80mm |
| 2 | 1 | 1 | 1 | 2 | 80x100mm |
| 3 | 1 | 1 | 2 | 3 | 100x120mm |
| 4 | 1 | 1 | 3 | 4 | |
Application:
a. Control and guide of water or flood.
b. Flood bank or guiding bank.
c. Preventing of rock breaking.
d. Water and soil protection.
e. Bridge protection.
f. Strengthening structure of soil.
g. Protection engineering of seaside area.
Package:
1. fold and press the gabion into bundle, then wrapped with 2-4
steel strips.
2. or according to customers' requirement.
|
|
