Hexagonal Hole Shape Gabions Application Wire Basket Retaining Walls Galvanized Gabion Mesh
Galvanized Gabion Mesh Information:
Galvanized gabion mesh widely used for making slope, rock,slope vegetation,rail-way or highway guardrail mesh stable. Also it can be made into basket, mesh mat for protecting dam which easily ruined by flood and lead to property losses. Therefore, application of gabion basket is the best solution of solving the problem that give dams lasting protection.
Galvanized Gabion Mesh details:
1.Assortment: Electro Glavanized Hexagonal Wire Mesh; Hot-dippped Galvanized Hexagonal Wire Mesh; Stainless Steel Hexagonal Wire Mesh; PVC Coated Hexagonal Wire Mesh.
2.Material: High Quality Low Carbon Steel Wire; Electro / Hot Dipped Galvanized Wire, Stainless Steel Wire.
3.Sizes: 1x1x0.5m,1x1x1m, 2x1x0.5m, 2x1x1m, 3x1x1m, 3x1x0.5m, 4x1x0.5m,
4x1x1m, 6x2x0.3m,Custom orders available.
4.Mesh Size:60*80mm, 80*100mm,100*120mm, 120*150mmCustom orders available.
5.Surface Treatment: Finish can be hot-dipped galvanized, galvanized aluminum alloy or
PVC coated, etc.
6.Weaving Patterns: Straight Twist; Reverse Twist;Double Twist;
Electro Galvanized before or after Weaving;
Hot-dipped Galvanized before or after Weaving;
7.Featuers:
Economic.
Simple installation.
Weather proof under natural destroy, corrosion resistant.
No collapse even under big scope of deforming.
Sludge in the stones is good for plant growing.
Good permeation can prevent the damage by hydrostatic.
Less transport freight.
Flexibility is good
Corrosion resistance
8.Application:
Control and guide of water or flood.
Flood bank or guiding bank.
Preventing of rock breaking.
Water and soil protection.
Bridge protection.
Strengthening structure of soil.
Protection engineering of seaside area.
Galvanized Gabion Mesh Package:
60-150sets per bundle,then wrapped with steel binding wire or plastic film if you need.we can also suppply pallet packing for convenient unloading.It according to your requirement.
| Woven / hexagonal wire mesh gabion basket | |
| Application | Control and guide of water or flood Strengthening structure of soil Protection engineering of seaside area |
| Material | Low carbon steel wire, Stainless steel wire, PVC coated wire |
| Surface Finish | Electro galvanized, Hot-dipped galvanized, Galfan coated, PVC coated |
| Connect Way | by Helical wire, by U post, H post |
| Material | galvanzied wire |
| Wire diameter | 2.0-4.0mm |
| Mesh Size | 60*80mm, 80*100mm, 80*120mm, 100*120mm, 100*150mm, 120*150mm |
| Surface treatment | hot-dipped galvanzied/PVC coated |
| Color | silver/green/black green |
| Application | soil, bridge construction, water bank |
| Length | Width | Height | Diaphragm | CUM | The tolerance |
| M | M | M | Unit | M3 | |
| 2 | 1 | 0.3 | 1 | 0.6 | |
| 3 | 1 | 0.3 | 2 | 0.9 | |
| 4 | 1 | 0.3 | 3 | 1.2 | length+-3% |
| 2 | 1 | 0.5 | 1 | 1 | width+-5% |
| 3 | 1 | 0.5 | 2 | 1.5 | height+-5% |
| 4 | 1 | 0.5 | 3 | 2 | |
| 1 | 1 | 0.5 | 0 | 1 | Hole size |
| 1.5 | 1 | 1 | 0 | 1.5 | 60x80mm |
| 2 | 1 | 1 | 1 | 2 | 80x100mm |
| 3 | 1 | 1 | 2 | 3 | 100x120mm |
| 4 | 1 | 1 | 3 | 4 |
|
|
